Performance and Features

1. Classification: Frame bending separates into level of bending and vertical bending. It is the latest and most advanced machines, which bends flat stee, squaresteel, round steel, angle steel, I-shaped steel, U-shaped steel, square tube, rectangular tube, round tube. Can be customized different mold in accordance with the requirements of uesers. Three rollers are initiative roller. There are three independent hydraulic motor driving, rolling speed fast, high efficiency.
2. Product using of frame bender: Frame bender is the more advanced sectional material molding equipment at home and abroad. It is widely other sectors of the production of various circular flange.
3. Features of frame bender: Frame bender can load material one time to complete the pre-bending, rolling round and school processes. The structure of frame bender is advanced, function of frame bender is full, according to the user. It can pul vertically and horizontally.
4. Working principle of frame bender: Frame bender is arc downward type sectional material rolling and bending machine.Two side rollers of machine are initiative rollers or three working rollers can rollers are initiative rollers. The position of upper roller is fixed the two side rollers rotating around fixed rotary center take arc up-and-down movement. Hydraulic controlling, displacement is liquid crystal display, which is of advantage to control the process of forming. Two sides equip with carrier roller device, which is of advantage to ensure the quality of rolling the non-symmetrical cross-section sectional material.
